Product Metal Fittings ATEX
Anaconda

Metal Fittings ATEX

The Anaconda IECEx-ATEX certified cable-hose-fittings together with the Anaconda Sealtite conduits represent the ideal solution for the mechanical protection of cables and for the connection of equipment in a safe and explosionproof way.

The temperature range of the standard version with an internal seal in EPDM is between -40°C and +100 °C, while the temperature range of the high temperature version with an internal seal in Silicone is between -70 °C and + 220 °C. The new barrier type with a 2 compound epoxy sealing has a temperature range from -60 °C till +130 °C.

The Anaconda IECEx-ATEX cable-hose-fittings are also available in EMC version (shielded) for the connection of armoured cables. They are available either in nickel plated brass or in stainless steel AISI-316. The protection grade as delivered is IP66, but can be increased to IP 68 by using an additional flat seal between body and enclosure (to be ordered separately).
